16 nm DPLL design completed





Our company continues to develop FDPLL. At this stage of the work, the FDPLL has been successfully synthesized in 16 nm TSMC. The necessary topological representations have been developed and tests of the generator's IP block have been completed. The jitter measured in the simulation does not exceed 2% in the output frequency range. The 16 nm FDPLL planned to be used as part of a new generation of multi-core MALT processors, including the MALT-Cv3 "Enceladus".



Technical specifications

Parameter Value
Reference frequency, MHz 1.2-3000
Output frequency, MHz 300-3000
Auxiliary frequency, MHz up to 1500
Period jitter (max), % 2
Power, mW 5
